Acer Incorporated Gateway GR160 F1(Intel Xeon X5670, 2.93 GHz) ssj_ops@100% = 893,973
ssj_ops@100% per JVM = 148,995
Test Sponsor: Acer Incorporated SPEC License #: 97 Test Method: Single Node
Tested By: Acer Incorporated Test Location: Taipei, R.O.C. Test Date: Oct 8, 2010
Hardware Availability: Jun-2010 Software Availability: Dec-2009 Publication: Nov 3, 2010
System Source: Single Supplier System Designation: Server Power Provisioning: Line-powered
Benchmark Results Summary
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     899,026
Calibration 2     900,006
Calibration 3     897,352
ssj_ops@calibrated=898,679
100% 99.5% 898,679 893,973
90% 90.1% 808,811 809,723
80% 79.8% 718,943 717,288
70% 70.0% 629,075 628,644
60% 60.1% 539,208 539,934
50% 50.0% 449,340 449,364
40% 39.9% 359,472 358,738
30% 29.8% 269,604 267,535
20% 19.8% 179,736 178,000
10% 10.0% 89,868 89,446
Active Idle   0 0
Graph of results
System Under Test
Set: 'sut'
Set Identifier: sut
Set Description: System Under Test
# of Identical Nodes: 1
Comment: None
Hardware
Hardware Vendor: Acer Incorporated
Model: Gateway GR160 F1(Intel Xeon X5670, 2.93 GHz)
Form Factor: 1U
CPU Name: Intel Xeon X5670
CPU Characteristics: Six-Core, 2.93 GHz, 12 MB L3 cache
CPU Frequency (MHz): 2933
CPU(s) Enabled: 12 cores, 2 chips, 6 cores/chip
Hardware Threads: 24 (2 / core)
CPU(s) Orderable: 1,2 chips
Primary Cache: 32 KB I + 32 KB D on chip per core
Secondary Cache: 512 KB I+D on chip per core
Tertiary Cache: 12 MB I+D on chip per chip
Other Cache: None
Memory Amount (GB): 12
# and size of DIMM: 6 x 2048 MB
Memory Details: 2GB 2Rx8 PC3-10600E; slots 1A, 2A, and 3A populated on each processor
Power Supply Quantity and Rating (W): 1 x 720
Power Supply Details: PWS-721P-1R
Disk Drive: 1 x 64GB SSD 2.5" SATA
Disk Controller: onboard SATA controller
# and type of Network Interface Cards (NICs) Installed: 1 x Dual-port Intel 82576EB Gigabit Ethernet controller
NICs Enabled in Firmware / OS / Connected: 2/2/1
Network Speed (Mbit): 1000
Keyboard: PS2
Mouse: PS2
Monitor: Direct
Optical Drives: No
Other Hardware: None
Software
Power Management: Power save enabled in OS
Operating System (OS): Windows Server 2008, Enterprise Edition
OS Version: R2
Filesystem: NTFS
JVM Vendor: IBM Corporation
JVM Version: IBM J9 VM (build 2.4, JRE 1.6.0 IBM J9 2.4 Windows Server 2008 amd64-64 jvmwa6460sr7-20091214_49398 (JIT enabled, AOT enabled)
JVM Command-line Options: -Xmn1100m -Xms1500m -Xmx1500m -Xaggressive -Xcompressedrefs -Xgcpolicy:gencon -XlockReservation -Xnoloa -XtlhPrefetch -Xlp
JVM Affinity: start /affinity [0xF, 0xF0, 0xF00,0xF000, 0xF0000, 0xF00000]
JVM Instances: 6
JVM Initial Heap (MB): 1500
JVM Maximum Heap (MB): 1500
JVM Address Bits: 64
Boot Firmware Version: P06
Management Firmware Version: 1.01
Workload Version: SSJ 1.2.6
Director Location: Controller
Other Software: IBM Websphere Application Server V7.0 for Windows on x86-64bit
Boot Firmware Settings
=
Management Firmware Settings
None
System Under Test Notes
Notes
None
JVM Instance Summary
JVM Instance ssj_ops@100%
WIN-2CJPLKUS673.001 151,022
WIN-2CJPLKUS673.002 147,530
WIN-2CJPLKUS673.003 147,015
WIN-2CJPLKUS673.004 152,054
WIN-2CJPLKUS673.005 146,140
WIN-2CJPLKUS673.006 150,210
ssj_ops@100% 893,973
ssj_ops@100% per JVM 148,995
Graph of per-instance results
JVM 'WIN-2CJPLKUS673.001' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     152,263
Calibration 2     152,080
Calibration 3     150,808
ssj_ops@calibrated=151,444
100% 99.7% 151,444 151,022
90% 90.2% 136,300 136,652
80% 79.7% 121,155 120,646
70% 70.5% 106,011 106,705
60% 60.0% 90,866 90,816
50% 49.8% 75,722 75,374
40% 39.2% 60,578 59,355
30% 29.6% 45,433 44,881
20% 19.8% 30,289 29,989
10% 10.0% 15,144 15,151
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-2CJPLKUS673.002' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     146,230
Calibration 2     147,625
Calibration 3     147,743
ssj_ops@calibrated=147,684
100% 99.9% 147,684 147,530
90% 89.9% 132,915 132,770
80% 79.8% 118,147 117,846
70% 69.5% 103,379 102,619
60% 60.1% 88,610 88,719
50% 50.0% 73,842 73,896
40% 40.1% 59,074 59,221
30% 29.5% 44,305 43,514
20% 19.6% 29,537 28,989
10% 9.9% 14,768 14,596
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-2CJPLKUS673.003' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     148,913
Calibration 2     147,997
Calibration 3     147,410
ssj_ops@calibrated=147,703
100% 99.5% 147,703 147,015
90% 90.3% 132,933 133,448
80% 79.7% 118,163 117,730
70% 70.2% 103,392 103,690
60% 60.4% 88,622 89,245
50% 50.0% 73,852 73,918
40% 40.1% 59,081 59,269
30% 29.8% 44,311 44,055
20% 19.4% 29,541 28,653
10% 10.0% 14,770 14,798
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-2CJPLKUS673.004' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     151,971
Calibration 2     153,244
Calibration 3     152,852
ssj_ops@calibrated=153,048
100% 99.4% 153,048 152,054
90% 89.8% 137,743 137,495
80% 80.0% 122,439 122,394
70% 69.4% 107,134 106,292
60% 59.7% 91,829 91,388
50% 50.4% 76,524 77,174
40% 40.0% 61,219 61,235
30% 29.7% 45,914 45,501
20% 20.0% 30,610 30,671
10% 9.9% 15,305 15,215
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-2CJPLKUS673.005' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     147,897
Calibration 2     147,183
Calibration 3     147,020
ssj_ops@calibrated=147,101
100% 99.3% 147,101 146,140
90% 90.4% 132,391 132,956
80% 80.1% 117,681 117,886
70% 70.3% 102,971 103,341
60% 60.5% 88,261 88,983
50% 49.8% 73,551 73,277
40% 40.0% 58,841 58,771
30% 30.0% 44,130 44,124
20% 20.1% 29,420 29,634
10% 10.0% 14,710 14,682
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
JVM 'WIN-2CJPLKUS673.006' Scores:
Target Load Actual Load ssj_ops
Target Actual
Calibration 1     151,753
Calibration 2     151,876
Calibration 3     151,520
ssj_ops@calibrated=151,698
100% 99.0% 151,698 150,210
90% 89.9% 136,528 136,402
80% 79.6% 121,359 120,787
70% 69.9% 106,189 105,997
60% 59.8% 91,019 90,782
50% 49.9% 75,849 75,725
40% 40.1% 60,679 60,887
30% 30.0% 45,509 45,459
20% 19.8% 30,340 30,064
10% 9.9% 15,170 15,004
Active Idle   0 0
Graph of results
See the JVM Instance Performance Report for additional details.
