SPEC® CINT2006 Result
Copyright 2006-2015 Standard Performance Evaluation Corporation
Hewlett Packard Enterprise
(Test Sponsor: HPE)
Integrity Superdome X
(288 core, 2.50 GHz, Intel Xeon E7-8890 v3)
The numactl mechanism was used to bind copies to processors. The config file option 'submit'
was used to generate numactl commands to bind each copy to a specific processor.
For details, please see the config file.
Stack size set to unlimited using "ulimit -s unlimited"
intel_idle.max_cstate=1 appended in kernel command line
Power profile set with:
cpupower -c all frequency-set -g performance
Benchmark installed under /dev/shm/cpu2006 and mounted with:
mount -o bind /dev/shm/cpu2006 /cpu2006
Transparent Huge Pages enabled with:
echo always > /sys/kernel/mm/transparent_hugepage/enabled
Filesystem page cache cleared with:
echo 1 > /proc/sys/vm/drop_caches
runspec command invoked through numactl i.e.:
numactl --interleave=all runspec <etc>
To run the Intel binaries based off the Intel 16.0 compiler (with SLES11 SP3), the following software was updated:
libgcc_s1 (32 and 64-bit versions) to version 4.8.3+r212056-6.3
glibc (32 and 64-bit versions) to version 2.19-17.72
libstdc++6 (32 and 64-bit versions) to version 4.8.3+r212056-6.3
Firmware settings:
Memory RAS Configuration set to Maximum Performance
Sysinfo program /cpu2006/config/sysinfo.rev6914
$Rev: 6914 $ $Date:: 2014-06-25 #$ e3fbb8667b5a285932ceab81e28219e1
running on hawk050os1 Tue Oct 20 09:29:23 2015
This section contains SUT (System Under Test) info as seen by
some common utilities. To remove or add to this section, see:
http://www.spec.org/cpu2006/Docs/config.html#sysinfo
From /proc/cpuinfo
model name : Intel(R) Xeon(R) CPU E7-8890 v3 @ 2.50GHz
16 "physical id"s (chips)
576 "processors"
cores, siblings (Caution: counting these is hw and system dependent. The
following excerpts from /proc/cpuinfo might not be reliable. Use with
caution.)
cpu cores : 18
siblings : 36
physical 0: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 1: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 2: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 3: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 4: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 5: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 6: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 7: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 8: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 9: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 10: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 11: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 12: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 13: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 14: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
physical 15: cores 0 1 2 3 8 9 10 11 16 17 18 19 20 24 25 26 27
cache size : 46080 KB
From /proc/meminfo
MemTotal: 4235779104 kB
HugePages_Total: 0
Hugepagesize: 2048 kB
/usr/bin/lsb_release -d
SUSE Linux Enterprise Server 11 (x86_64)
From /etc/*release* /etc/*version*
SuSE-release:
SUSE Linux Enterprise Server 11 (x86_64)
VERSION = 11
PATCHLEVEL = 3
uname -a:
Linux hawk050os1 3.0.101-0.47.55-bigsmp #1 SMP Thu May 28 08:25:11 UTC 2015
(dc083ee) x86_64 x86_64 x86_64 GNU/Linux
run-level 3 Oct 20 08:13 last=S
SPEC is set to: /cpu2006
Filesystem Type Size Used Avail Use% Mounted on
tmpfs tmpfs 2.0T 3.8G 2.0T 1% /dev/shm
Additional information from dmidecode:
Warning: Use caution when you interpret this section. The 'dmidecode' program
reads system data which is "intended to allow hardware to be accurately
determined", but the intent may not be met, as there are frequent changes to
hardware, firmware, and the "DMTF SMBIOS" standard.
BIOS HP Bundle: 007.005.000 SFW: 033.161.000 07/18/2015
Memory:
222x HP 36ASF2G72LZ-2G1A1 16 GB 2133 MHz, configured at 1600 MHz
18x HP HMA42GL7MFR4N-TF 16 GB 2133 MHz, configured at 1600 MHz
16x HP M386A2G40DB0-CPB 16 GB 2133 MHz, configured at 1600 MHz
128x not defined not defined
(End of data from sysinfo program)
Regarding the sysinfo display about the memory installed, the correct amount of
memory is 4 TB and the dmidecode description should have three lines reading as:
222x HP 36ASF2G72LZ-2G1A1 16 GB 2133 MHz, configured at 1600 MHz
18x HP HMA42GL7MFR4N-TF 16 GB 2133 MHz, configured at 1600 MHz
16x HP M386A2G40DB0-CPB 16 GB 2133 MHz, configured at 1600 MHz
Environment variables set by runspec before the start of the run:
LD_LIBRARY_PATH = "/cpu2006/libs/32:/cpu2006/libs/64:/cpu2006/sh"
Binaries compiled on a system with 1x Intel Core i5-4670K CPU + 32GB
memory using RedHat EL 7.1
